Product features

• Phase Balance - Support three phase imbalance
• Grid Support Functionality - Time of use shifting and peak shaving capabilities to grid
• High Efficiency Design - Maximum efficiency of 98.4%
• Integrated Energy Management - Intelligent EMS function
• 2 MPPT and 4 DC input: Max 26A DC input current

Weight: 25.1 kg
Rated Power: 10,000 W
Min PPT Voltage: 160 V
Max PPT Voltage: 850 V
DC Startup Voltage: 160 V
DC Shutdown Voltage: 160 V
Max Input Voltage: 1,000 V
Max DC Power: 16,000 W
Max AC Power (5 Minutes): 11,000 W
Surge AC Power (1 Second): 12,000 W
Max DC Current: 52 A
Max DC Inputs: 4
Has DC Fuses: 0
Connector: MC4
Included Connectors: 4
Euro Efficiency: 97.7 %
Transformer: HF
MPPT Quantity : 2
Has Integrated DC Switch: Yes
Warranty: 5 years
